Description
Description
Carli Suspension
Carli Pintop 2.5 Leveling System Base 2.5in Lift 2014–2022 Ram 2500 Coil Rear
The Carli Pintop 2.5 Leveling System is built for Ram 2500 owners who want a quality big-shock suspension system with moderate lift height, improved ride quality, and strong light- to medium-duty off-road performance. This system delivers a level stance with a 2.5-inch front lift while maintaining the factory rear coil springs to preserve payload and hauling capacity.
At the heart of the system are Carli-specific, blueprinted King 2.5-inch remote reservoir shocks on all four corners. Compared to a 2.0-inch shock, the 2.5-inch shock body provides 55% more piston surface area for increased control and heat capacity. Carli engineers designed custom pistons and tuned the shocks in-house to improve ride quality, handling, and predictability both on-road and off-road.
Key Features:
-
2.5-inch front lift for a leveled stance
-
Carli linear rate front coil springs
-
Carli-specific King 2.5-inch remote reservoir shocks
-
Rear piggyback reservoir shocks tuned for factory rear coil springs
-
Custom Carli shock pistons for proper base flow rates
-
17-4 stainless steel shock shafts for durability and corrosion resistance
-
Adjustable track bar to recenter the axle at the taller ride height
-
Front reservoir mounts display the 9-inch remote reservoirs over the front tire
-
E-brake line relocation brackets provide clearance for oversized rear shocks
-
Maintains factory rear coil springs, payload, and hauling capacity
-
Improves off-road capability without sacrificing towing manners
Notes:
-
This system is not upgradeable to any other Carli Suspension system.
-
Designed for customers wanting a quality big-shock system with off-road capability, minimal lift, and no reduction in payload or hauling capacity.
-
Slight eccentric bolt compensation is recommended to correct caster after installation.
-
No radius arm drops are included.
-
Customers may experience slight front coil spring bow at the 2.5-inch lift height without radius arm drop brackets.
-
Radius arm drop brackets can be added separately to alleviate coil bow and recenter caster adjustment if needed.
-
This system will result in tight, responsive handling.
-
Carli 3-inch suspension systems will ride softer in the rear due to their included reduced-capacity rear springs.
-
Ride quality can be substantially improved with the addition of a Carli torsion sway bar.
-
A Carli low-mount steering stabilizer is recommended for any tire larger than factory size.
-
Recommended tire size is 35 inches.
-
Recommended wheel width is no more than 9 inches.
-
Recommended backspacing is 5.5 to 6 inches.
-
An 18-inch diameter wheel is recommended for optimal ride quality.
-
Recommended unloaded tire pressure is 45 PSI front and 40 PSI rear.
-
King shocks use plated steel bodies. If exposed to inclement weather for extended periods, Carli recommends wrapping the shocks in 3M film to provide a replaceable moisture barrier.
-
King shock oil is rated to -55°F.
Vehicle Fitment:
-
2014–2025 Ram 2500 Big Horn
-
2014–2025 Ram 2500 Laramie
-
2014–2015 Ram 2500 Laramie Limited
-
2014–2021 Ram 2500 Laramie Longhorn
-
2016–2025 Ram 2500 Limited
-
2021–2025 Ram 2500 Limited Longhorn
-
2014–2015, 2019–2025 Ram 2500 Lone Star
-
2014–2016 Ram 2500 Outdoorsman
-
2014–2025 Ram 2500 Power Wagon
-
2023–2025 Ram 2500 Rebel
-
2014–2018 Ram 2500 SLT
-
2024–2025 Ram 2500 Special Service
-
2014–2025 Ram 2500 Tradesman
SKU: CS-DPT25-LVL-1419-D
