Description
Description
2009–2013 Ford F-150 owners — meet the BDS Suspension Lift Kit, engineered specifically for your truck. Front strut spacers retain your factory struts while delivering your chosen lift height. Out back, choose your rear block size and shock package to dial in exactly the stance and performance you need — whether you're hauling Monday through Friday or tearing up trails on the weekend.
Why Choose the BDS Suspension Lift Kit?
- Factory Strut Retention – Front strut spacers work with your existing struts, keeping costs down without sacrificing lift.
- Adjustable Rear Stance – Choose 3-inch or 4-inch rear blocks to set your rake from level to slightly tail-high.
- Big Tire Capable – Engineered to clear up to 37-inch tires.
- Corrected Control Arm Geometry – High-strength, 1/4" steel construction crossmembers correct lower control arm geometry.
- Stronger Steering – High-strength, CNC machined replacement steering knuckles improve strength while correcting steering angles.
- No Track Width Change – Lift system does not change the front track width of the vehicle.
- Off-Road Protection – Heavy-duty differential skid plate improves off-road protection.
- Made in the USA – BDS builds this kit domestically.
Rear Lift Options
- 4-Inch Block Kit – Level to tail-high appearance.
- 3-Inch Block Kit – Tail-low to level stance.
Rear Shock Options
- NX2 Nitro Series – Nitrogen-charged, twin-tube design; 10-stage velocity-sensitive valving; dual-welded ends for increased strength; 1-3/8-inch high-flow piston; self-lubricating seals; silver powder coat finish.
- FOX 2.0 Performance Series – 2-inch impact extruded aluminum body; internal floating piston (IFP) monotube design; CNC machined 6061-T6 aluminum mounting ends; massive 5/8-inch hard chrome plated heat-treated alloy steel shaft; race-developed high-flow piston design; application-specific valving; long-lasting clear anodized finish.
Recommended Tires & Wheels
(Trimming may be required)
- 37 x 12.5 with 20 x 9 and 5 in. Backspace
- 35 x 12.5 with 20 x 9 and 4.5 in. Backspace
- 35 x 12.5 with 18 x 9 and 4.5 in. Backspace
Fits These Models
2009–2013 Ford F-150
Specifications
- Crossmember construction: 1/4" high-strength steel
- Steering knuckles: High-strength, CNC machined replacement units
- NX2 piston diameter: 1-3/8 inch
- NX2 finish: Silver powder coat
- FOX 2.0 body: 2-inch impact extruded aluminum
- FOX 2.0 shaft: 5/8-inch hard chrome plated heat-treated alloy steel
- FOX 2.0 mounting ends: CNC machined 6061-T6 aluminum
- FOX 2.0 finish: Clear anodized
- NX2 valving: 10-stage velocity-sensitive
- NX2 design: Twin-tube, nitrogen-charged
- FOX 2.0 design: Internal floating piston (IFP) monotube
Key Features at a Glance
- Strut Spacer Front Lift – Retains factory struts for a clean, cost-effective install.
- Dual Rear Block Sizes – 3-inch or 4-inch blocks let you set your exact stance.
- Two Shock Tiers – NX2 for daily driving comfort; FOX 2.0 IFP for serious off-road performance.
- 37-Inch Tire Clearance – Room to run aggressive rubber.
- USA Made – BDS quality, built domestically.
Notes
- Trimming may be required for some tire/wheel combinations.
- Rear lift height and stance depend on block size selected (3-inch or 4-inch).
- Rear shock must be selected separately: NX2 Nitro Series or FOX 2.0 Performance Series IFP.
